| System |
Operation system |
Embedded Linux OS |
| Online visitor |
Support 4 visitors at the same time |
| Image Capture |
Image sensor |
HI3516E V300 1/3 inch Progressive Scan CMOS |
| Minimum Illumination |
0.5Luxuff08Color modeuff09,0.1Luxuff08B&W modeuff09 |
| Lens |
4.0mm |
| View Angle |
101u00b0uff08diagonaluff09 |
| Night vision |
The dual filter switches automaticallyuff0c2pcs 28mil patch IR LED IR irradiation distance:5~10m |
| Video |
Encode format |
H.264 main profile/H.264+ main profile/Motion-JPEG/JPEG |
| Resolution |
2560×1440@30pfs/640*360@15pfs |
| Bit rate/Frame rate/Display frequency |
128uff5e4096kbps/1uff5e30pfs/60Hzu300150Hz |
| Image adjustment |
Brightness and contrast are adjustable |
| Audio |
Input |
Built-in -38 dB microphone |
| Output |
Built-in speaker(8u03a91W) |
| Sampling frequency / width |
8KHz/16bit |
| Compression standard |
ADPCM/32kbps |
| Network |
Ethernet |
RJ-45(10 / 100Base-T) |
| Protocols |
TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,RTSP,P2P etc |
| Wireless LAN |
IEEE802.11b/g/n |
| Wireless LAN Frequency |
2.4~ 2.4835GHz; 5G |
| Wireless LAN security |
64/128-bit WEP/WPA-PSK /WPA2-PSK data encryption |
| Pan-tilt |
Pan-tilt |
Panuff1a355u00b0, tiltuff1a110u00b0 |
| Preset position |
PC APPuff1asupport 16 positions, Phone APP:support 5 positions |
| Memory |
Socket |
TF Push-push socket,Maximum support 256GB; Cloud Storage |
| Alarm |
Alarm Trigger |
Motion detection, Humanoid detection, Humanoid tracking, Crying detection, Smoke detector alarm detection, absence monitoring |
| Physical Environmental |
Rated voltage |
DC 5Vu00b15% |
| Power consumption |
Related power: 2.8W(IR LED on)uff0cMaximum poweruff1a4.3Wuff08Pan&Tilt onuff09 |
| Operating condition |
Temperature:-10uff5e50u2103,humidity:uff1c90% |
| Weight |
Net: 185 g Grossuff1a450 g(Note: in kind prevail) |
| Package size |
185x125x92 mm(Lu00d7Wu00d7H) |
